Yard Scrapper

The HNH Yard Scraper is an ideal attachment for telehandlers, providing a fast and efficient solution for cleaning yards, loading areas, farm tracks, and hardstanding. Thanks to the telehandler’s excellent reach, lift capacity, and visibility, operators can move and scrape material quickly while maintaining precise control across large surface areas.

When fitted to a telehandler, the yard scraper excels at pushing loose material, clearing mud, slurry residue, gravel, and debris, and maintaining tidy, safe working environments. The rigid design and wide working width allow for efficient coverage, reducing clean-up time and minimising machine movements compared to smaller attachments.

HNH Yard Scraper – Specifications

The HNH Yard Scraper is available in three models, designed to suit a range of telehandlers and site requirements. All models feature a heavy-duty U-shaped frame and hydraulic side tilt for efficient yard and surface cleaning.

Model: SPU-2.6

• Working width: 2600 mm

• Depth: 800 mm

• Height: 880 mm

• Weight: approx. 470 kg

• Cutting edge: 150 × 20 mm HB500

• Suitable for: Telehandlers and loaders requiring a compact, manoeuvrable scraper

Model: SPU-3.1

• Working width: 3100 mm

• Depth: 900 mm

• Height: 1000 mm

• Weight: approx. 620 kg

• Cutting edge: 200 × 20 mm HB500

Model: SPU-3.6

• Working width: 3600 mm

• Depth: 900 mm

• Height: 1000 mm

• Weight: approx. 700 kg

• Cutting edge: 200 × 20 mm HB500

Standard Features (All Models)

• Replaceable rubber blade – 50 mm thick

• Hydraulic cylinders on both sides with up to 30° angle adjustment

• Heavy-duty steel side plates (10 mm and 12 mm)

• Body steel thickness: 6 mm

• U-shaped reinforced frame for strength and rigidity

• Hydraulic hoses included

• Custom mounting available

Note: Overall weight may vary depending on mounting configuration.

 Shipping & Delivery Information

Due to the size and weight of this machinery attachment, delivery is arranged using specialist couriers or pallet freight services. Shipping cost is included in the price, or confirmed separately for oversized items.

Delivery times are estimates only and typically range from 2–7 business days within the UK mainland once dispatched. Remote areas may require additional transit time.

 Delivery Method & Access

Most machinery attachments are delivered kerbside only. It is the customer’s responsibility to ensure suitable access for delivery vehicles and appropriate equipment or manpower for unloading at the delivery location.

Please ensure someone is available to receive the goods at the agreed delivery address.

 Inspection on Arrival

All items must be inspected upon delivery. Any visible damage must be noted with the carrier at the time of delivery and reported to us within 48 hours of receipt.

Failure to report damage within this timeframe may affect your ability to make a claim.

 Risk & Responsibility

Risk of loss or damage passes to the customer once the item has been delivered. We are not responsible for delays caused by couriers, weather conditions, access restrictions, or other circumstances beyond our control.

 International & Special Orders

For international or special-order items, additional shipping charges, customs duties, or extended lead times may apply. Customers are responsible for any import taxes or clearance fees.

All attachments include a 12-month warranty covering manufacturing faults. This excludes wear and tear, consumable parts, misuse, accidental damage, incorrect installation, overloading, and unauthorised repairs or modifications.
